Products Catalog 2015-2016 •www.ouellet.com 113
OTH3600-GA
Non Programmable Electronic Thermostat
for Floor Heating System
OTH3600P-GA
Programmable Electronic Thermostat
for Floor Heating System
Compliance with standard
CAN/CSA-C828-13
Compliance with standard
CAN/CSA-C828-13
Type
• Non programmable, electronic, double-pole,
4-wire thermostat for floor heating system.
Color
• Standard: white.
Voltage
• 120/208/240V, 50/60 Hz.
Rating
• 15A at 120/208/240V.
Control
• 15-minute cycle.
• This thermostat does not have any auxiliary contact,
it cannot be used with the TR1310-120/240GA slave unit.
• Resolution and precision: ± 0.5 °C (1 °F).
Temperature range
• Floor: 5 °C (40 °F) to 30 °C (86 °F).
• Ambient: 5 °C (40 °F) to 30 °C (86 °F).
Temperature control mode
• A mode: Ambient temperature control and possibility of limiting
the temperature of the floor using an external temperature sensor.
• F mode: Floor temperature control using and external temperature
sensor and possibility of limiting the ambient temperature.
Display
• Digital display of actual and setpoint temperature (°C or °F),
heating level.
• GFCI fault indicator.
• Backlit.
Installation
• 4-wire thermostat with ambient and floor sensor.
Warranty
• 3-year warranty against defects.
Type
• Programmable, electronic, double-pole,
4-wire thermostat for floor heating system.
Color
• Standard: white.
Voltage
• 120/208/240V, 50/60Hz.
Rating
• 15A at 120/208/240V.
Control
• 15-minute cycle.
• Resolution and precision: ± 0.5 °C (1 °F).
• Auxiliary contact offers the possibility of controlling supplemental heat
sources to be added by either using a slave module (TR1310-120/240GA)
for heated floors or using a low voltage relay and a low voltage
transformer for an electric heater.
Temperature control mode
• A mode: Ambient temperature control and possibility of limiting
the temperature of the floor using an external temperature sensor.
• F mode: Floor temperature control using and external temperature
sensor and possibility of limiting the ambient temperature.
Temperature range
• Floor: 5 °C (40 °F) to 30 °C (86 °F).
• Ambient: 5 °C (40 °F) to 30 °C (86 °F).
Display
• Digital display of actual and setpoint temperature (°C or °F),
heating level, actual mode and clock (12 or 24-hour format).
• Temperature setpoint and settings are permanently recorded.
• Time and date retained up to 8 hours during a power outage.
• GFCI fault indicator.
• Backlit.
Program
• 7 days, 4 settings/day.
• Pre-programmed or personalized schedule.
Mode
• Automatic, Manual, No freeze and Sleep.
• Boost (timer) available in ambient mode with auxiliary contact.
Installation
• 4-wire thermostat with ambient and floor sensor.
Warranty
• 3-year warranty against defects.
OTH3600-GA Features
OTH3600P-GA Features
