OHX
Models
kW
Product #
Price
BTU/hr
cfm
T° Rise
T° Code
2
Weight
1
208V (1 ph) 208V (3 ph) 240V (1 ph) 240V (3 ph) 480V (3 ph) 600V (3 ph)
°C
°F
lb kg
5.0
OHX05008 OHX05038 OHX05000 OHX05030 OHX05034 OHX05036
4541.00
17060 400 21.2 38.1 T3B 188 85.3
7.5
OHX07508 OHX07538 OHX07500 OHX07530 OHX07534 OHX07536
4869.00
25590 600 22.4 40.4 T3B 188 85.3
10.0
-
OHX10038 OHX10000 OHX10030 OHX10034 OHX10036
5199.00
34120 800 21.6 38.8 T3B 192 87.1
15.0
-
OHX15038
-
OHX15030 OHX15034 OHX15036
5364.00
51180 1200 21.7 39.1 T3B 224 101.6
20.0
-
-
-
-
OHX20034 OHX20036
5698.00
68240 1700 20.7 37.3 T3B 224 101.6
25.0
-
-
-
-
OHX25034 OHX25036
6239.00
85300 2100 20.8 37.5 T3B 261 118.4
30.0
-
-
-
-
OHX30034 OHX30036
6622.00
102360 3000 17.5 31.5 T3B 261 118.4
35.0
-
-
-
-
OHX35034 OHX35036
7166.00
119420 3000 20.4 36.7 T3A 261 118.4
1
Shipping weight.
2
Temperature code: T3B = 165 °C (329 °F), T3A = 180 °C (356 °F).
Standard color is red.
Options
Product #
Price
Description
Factory
Installed
Kit
OHX-24
No Charge
Transformer and contactor for 24V (also compatible with OHX-TM)
3
-
OHX-DIS
1460.00
Disconnect switch
3
-
OHX-MB1
227.00
Basic mounting bracket, 5 to 10kW units
-
3
OHX-MB2
227.00
Basic mounting bracket, 15 to 20kW units
-
3
OHX-MB3
227.00
Basic mounting bracket, 25 to 35kW units
-
3
OHX-MM1
273.00
Wall mounting bracket, 5 to 10kW units
-
3
OHX-MM2
273.00
Wall mounting bracket, 15 to 20kW units
-
3
OHX-MM3
273.00
Wall mounting bracket, 25 to 35kW units
-
3
OHX-MS
150.00
Hanging mounting bracket, all models
-
3
OHX-MT1
273.00
Pipe mounting bracket, 5 to 10kW units
-
3
OHX-MT2
273.00
Pipe mounting bracket, 15 to 20kW units
-
3
OHX-MT3
273.00
Pipe mounting bracket, 25 to 35kW units
-
3
OHX-T
448.00
Explosion-proof built-in thermostat, range 5 °C (40 °F) to 27 °C (80 °F), 22A at 277V
3
-
OHX-TWG
482.00
Explosion-proof built-in thermostat, range 5 °C (40 °F) to 27 °C (80 °F), 22A at 277V with guard
3
-
OHX-TM
448.00
Explosion-proof wall thermostat, range 5 °C (40 °F) to 27 °C (80 °F), 22A at 277V
-
3
OHX-TMWG
482.00
Explosion-proof wall thermostat, range 5 °C (40 °F) to 27 °C (80 °F), 22A at 277V with guard
-
3
OHX-TG
34.00
Thermostat guard for built-in or wall thermostat
-
3
XDC-01
1073.00
Explosion-proof wall mount disconnect switch
-
3
Approved locations
Temperature limitations
Class I, Divisions 1 and 2, Groups C and D.
Class II, Divisions 1 and 2, Groups F and G.
Temperature code: T3B (5 to 30kW), T3A (35kW).
Class I, Zones 1 & 2 , Groups IIA & IIB, T3.
Ambient temperature: -45 °C to 40 °C (-49 °F to 104 °F).
Maximum altitude: 3048 m (10 000 ft.) above sea level.
E
C
D
168 mm
6
5/8
"
118 mm
4
5/8
"
6 mm
1/4
"
6 mm
1/4
"
Front View
Side View
Top View
279 mm
11"
Louvres
36 mm max.
1
3/8
” max.
86 mm
3
3/8
”
86 mm
3
3/8
”
57 mm
2
1/4
”
10 mm
3/8
”
214 mm
8
7/16
”
127 mm
5”
1”NPT
Main Electrical Entry
for Disconnect Option
1”NPT
Main Electrical Entry
No Disconnect Fitted
95 mm
3
3/4
”
B
A
G
max.
3/4
“ NPT
External Thermostat
Entry
F
4 X Ø
9/16
" (14 mm)
Mounting Holes
Models
Fan
Dim.
A
B
C
D
E
F
G
5 to 10kW
12”
305 mm
in.
(mm)
7.5
(190.5)
18.19
(462)
16.3
(414)
19
(483)
19.45
(494)
3.1
(79)
22.25
(565)
15 to 20kW
16”
406.4 mm
in.
(mm)
7.5
(190.5)
22.28
(566)
20.28
(515)
23
(584)
23.46
(596)
5.1
(130)
22.25
(565)
25 to 35kW
20”
508 mm
in.
(mm)
7.5
(190.5)
26.26
(667)
24.29
(617)
27
(686)
27.44
(697)
7.1
(180)
23.25
(591)
