Products Catalog 2015-2016 •
46
Product #
Price
Description
Factory
Installed
Kit
All ELSR Models
ECA-JB1
375.00
Junction box with power connection and termination for single connection
c/w label and fastener
-
3
ECA-JB2
525.00
Junction box with power connection and termination for double connection
c/w label and fastener
-
3
ECA-TYS6-280
13.50
Stainless steel fastener 6.8 mm x 152.4 mm (1/4'' x 6'')
-
3
ECA-TYS9-280
14.75
Stainless steel fastener 6.8 mm x 228.6 mm (1/4'' x 9'')
-
3
ECA-TYS12-280
17.25
Stainless steel fastener 6.8 mm x 304.8 mm (1/4'' x 12'')
-
3
ECA-TYS18-280
19.50
Stainless steel fastener 6.8 mm x 457.2 mm (1/4'' x 18'')
-
3
ECA-TYS24-280
24.00
Stainless steel fastener 6.8 mm x 609.6 mm (1/4'' x 24'')
-
3
ECA4160TB
13.50
Roof clip, single hole strap, 3/4'' (Qty 25)
-
3
EL-WS01F
2.50
Warning label/sign, French
-
3
EL-WS02E
2.50
Warning label/sign, English
-
3
ELB-03
50.00
Self-adhesive glass fber tape, max. T = 90 °C (194 °F), 50 m (165 ft.)
-
3
ELB-06C
55.00
Self-adhesive aluminum tape, max. T = 80 °C (176 °F), 50 m (165 ft.)
-
3
ELB-18
10.00
Gutter and downspout mounting plate
-
3
ELB-20
21.00
Downspout mounting plate
-
3
ELB-21
27.75
Gutter mounting plate
-
3
ELB-16-10
9.00
Mechanical fastener, plastic strap (L 102 mm x 2.5 mm)
-
3
ELB-16-20
12.00
Mechanical fastener, plastic strap (L 200 mm x 3.6 mm)
-
3
ELB-16-36
22.00
Mechanical fastener, plastic strap (L 360 mm x 4.8 mm)
-
3
ELSR-NA Models
EL-ECN-EX
1,2
18.00
End termination for ELSR-NA
-
3
ELVB-SRAN
40.00
Power connection without cable gland
-
3
ELVB-SRAN-3/4-ST
2
80.00
Power connection with steel/zinc cable gland/ftting, 3/4'' NPT, non-hazardous location
-
3
ELSR-WA Models
EL-ECW
1,2
18.00
End termination for ELSR-WA
-
3
ELVB-SRAW-3/4-ST
70.00
Power connection with steel/zinc cable gland, 3/4'' NPT, non-hazardous location
-
3
ELSR-MA Models
EL-ECM
1,2
18.00
End termination for ELSR-MA
-
3
EL-ECMF
3
31.00
End termination for ELSR-MA-BF
-
3
ELVB-SRAM-3/4-ST
2
70.00
Power connection with steel/zinc cable gland/ftting, 3/4'' NPT, non-hazardous location
-
3
ELSR-HA Models
EL-ECH-EX
1,2
18.00
End termination for ELSR-HA
-
3
ELVB-SRAH-3/4-ST
2
80.00
Power connection with steel/zinc cable gland/ftting, 3/4'' NPT, non-hazardous location
-
3
ELVB-SREX-3/4-BR-HT
1,2
220.00
Power connection with brass cable gland, 3/4'' NPT, hazardous location
-
3
ELVB-SREX-20-BR-HT
1,2
210.00
Power connection with brass cable gland, M20, hazardous location
-
3
Options
OSR
1
Minimum installation temperature -45 °C (-49 °F).
2
Coverage: braiding 80%, aluminum foil 100%.
3
Minimum installation temperature -13 °C (-25 °F).
Eltherm® Correction Factors/Multipliers for Operation of Heating Cables in 208V
To calculate the corrected power output for operation in 208V, multiply the published output at 240V (in W/ft.) by the nominal output factor provided
for the applicable heating cable type.
To calculate maximum heating circuit lengths for operation in 208V (tables provided in product data sheets), multiply the published max. heating circuit
length at 240V provided for the applicable heating cable type.
Heating Cable
Nominal Output
208V vs. 240V
Heating Circuit Length
208V vs. 240V
Eltherm® ELSR-HA Correction Factors/Multipliers for 208V Operation
ELSR-HA-XX-2
0.74
1.00
Eltherm® ELSR-NA Correction Factors/Multipliers for 208V Operation
ELSR-NA-XX-2
0.88
0.93
Eltherm® ELSR-MA Correction Factors/Multipliers for 208V Operation
ELSR-MA-XX-2
0.82
1.00
Eltherm® ELSR-WA Correction Factors/Multipliers for 208V Operation
ELSR-WA-XX-2
0.80
1.00
