Products Catalog 2015-2016 •
75
OLI
Options
1
These 2-wire relays with transformer can't supply of 3-wire low voltage thermostats.
2
For 1-phase model only.
3
For the U.S. only: The nominal current of the unit must not exceed 80% of the capacity of the disconnect.
Electronic relay (1 or 3-phase) available upon request.
For the options available as factory installed and kit, if not mentioned on the order, will automatically be shipped as a kit.
Product #
Price
Description
Factory
Installed
Kit
Finish
OLI-BD
+10%
Clean back
3
-
OLI-CE
639.00
Outside corner, 4 in. (102 mm)
-
3
OLI-CI
639.00
Inside corner, 4 in. (102 mm)
-
3
OLI-CTR
141.00
Relay box, 12 in. (305 mm)
-
3
OLI-PE
85.00
Pedestal kit (2), 3 in. (76 mm)
-
3
OLI-SO-27
130.00
Sub-base, 27
3/16
in. (690 mm)
-
3
OLI-SO-37
140.00
Sub-base, 37
3/16
in. (944 mm)
-
3
OLI-SO-47
153.00
Sub-base, 47
3/16
in. (1198 mm)
-
3
OLI-SO-57
177.00
Sub-base, 57
3/16
in. (1452 mm)
-
3
OLI-SO-65
184.00
Sub-base, 65
3/16
in. (1655 mm)
-
3
OLI-SV-27
449.00
Empty cabinet, 27
3/16
in. (690 mm)
-
3
OLI-SV-37
525.00
Empty cabinet, 37
3/16
in. (944 mm)
-
3
OLI-SV-47
623.00
Empty cabinet, 47
3/16
in. (1198 mm)
-
3
OLI-SV-57
686.00
Empty cabinet, 57
3/16
in. (1452 mm)
-
3
OLI-SV-65
817.00
Empty cabinet, 65
3/16
in. (1655 mm)
-
3
Controls
OLI-CTT
127.00
Single-pole relay, coil 240V: 25A at 240V, 10A at 600V
3
-
OLI-CTT2
171.00
Double-pole relay, coil 240V: 25A at 240V, 10A at 600V
3
-
OLI-DIS40
3
132.00
Disconnect switch, triple-pole, 40A at 600V
3
-
OLI-PM
262.00
Pneumatic relay, 20A at 600V
3
-
OLI-R
114.00
Single-pole relay, coil 24V, without transformer: 22A at 208V, 240V - 18A at 347V
3
3
OLI-R2
171.00
Double-pole relay, coil 24V, without tranformer: 25A at 240V - 10A at 600V
3
3
OLI-R2-30
166.00
Double-pole relay, coil 24V, without transformer, 30A at 600V max.
3
3
OLI-RT-208
127.00
Single-pole relay, coil 24V, with transformer 208V/24V, 4500W, 22A at 208V
3
3
OLI-RT-240
127.00
Single-pole relay, coil 24V, with transformer 240V/24V, 5200W, 22A at 240V
3
3
OLI-RT-277
127.00
Single-pole relay, coil 24V, with transformer 277V/24V, 5200W, 19A at 277V
3
3
OLI-RT-347
127.00
Single-pole relay, coil 24V, with transformer 347V/24V, 6000W, 18A at 347V
3
3
OLI-RT-600
1
127.00
Single-pole relay, coil 24V, with transformer 600V/24V, 6000W, 10A at 600V (2-wire only)
3
3
OLI-T-AV
2
95.00
Single-pole tamperproof thermostat: 30A at 250V max. - 15A at 600V max.
3
3
OLI-T2-AV
160.00
Double-pole tamperproof thermostat: 30A at 250V max. - 15A at 600V max.
3
3
Transformers
OLI-TRF208/24-50
155.00
Transformer 208V/24V, 50VA
3
-
OLI-TRF240/24-50
155.00
Transformer 240V/24V, 50VA
3
-
OLI-TRF277/24-50
155.00
Transformer 277V/24V, 50VA
3
-
OLI-TRF347/24-50
155.00
Transformer 347V/24V, 50VA
3
-
OLI-TRF600/24-50
155.00
Transformer 600V/24V, 50VA
3
-
OLI-TRF277/240-50
155.00
Transformer 277V/240V, 50VA
3
-
OLI-TRF347/240-50
155.00
Transformer 347V/240V, 50VA
3
-
OLI-TRF600/240-50
155.00
Transformer 600V/240V, 50VA
3
-
