Ouellet Canada - Products Catalog - page 85

Products Catalog 2015-2016 •www.ouellet.com 83
OACP
1 208V = 75% of wattage at 240V.
2 Not compatible with models at 120V.
3 For the U.S. only: The nominal current of the unit must not exceed 80% of the capacity of the disconnect.
Add "BL" for white, "AM" for almond. Optional colors shown in the color chart section are available with a 10% upcharge.
For options available as factory installed and kit, if not mentioned on the order, will automatically be shipped as a kit.
277V available upon request.
Models
Watts Volts
(1 ph) Product # Price Unit Weight
lb kg
1500 120 OACP1502 483.00 single 24.0 10.9
4000 208 OACP4008 528.00 single 24.0 10.9
4800 208 OACP4808 555.00 single 24.0 10.9
8000 208 OACP8008 1237.00 double 50.0 22.7
1500/1125 1 240/208 OACP1500 483.00 single 24.0 10.9
2000/1500 1 240/208 OACP2000 483.00 single 24.0 10.9
3000/2250 1 240/208 OACP3000 494.00 single 24.0 10.9
4000/3000 1 240/208 OACP4000 528.00 single 24.0 10.9
4800/3600 1 240/208 OACP4800 555.00 single 24.0 10.9
6000/4500 1 240/208 OACP6000 1087.00 double 50.0 22.7
8000/6000 1 240/208 OACP8000 1169.00 double 50.0 22.7
1500 347 OACP1507 640.00 single 28.0 12.7
2000 347 OACP2007 640.00 single 28.0 12.7
3000 347 OACP3007 664.00 single 28.0 12.7
4000 347 OACP4007 685.00 single 28.0 12.7
6000 347 OACP6007 1427.00 double 50.0 22.7
8000 347 OACP8007 1639.00 double 50.0 22.7
1500 480 OACP1504 675.00 single 28.0 12.7
2000 480 OACP2004 675.00 single 28.0 12.7
3000 480 OACP3004 697.00 single 28.0 12.7
4000 480 OACP4004 721.00 single 28.0 12.7
6000 480 OACP6004 1427.00 double 50.0 22.7
8000 480 OACP8004 1639.00 double 50.0 22.7
1500 600 OACP1506 675.00 single 28.0 12.7
2000 600 OACP2006 675.00 single 28.0 12.7
3000 600 OACP3006 697.00 single 28.0 12.7
4000 600 OACP4006 721.00 single 28.0 12.7
4800 600 OACP4806 761.00 single 28.0 12.7
6000 600 OACP6006 1427.00 double 50.0 22.7
8000 600 OACP8006 1639.00 double 50.0 22.7
Options
Product # Price Description Factory
Installed Kit
OAWH-BSA 67.00 Surface mounting box for an extruded aluminum front grille, single unit - 3
OAWH-BSA2 133.00 Surface mounting box for an extruded aluminum front grille, double unit - 3
OAC-BS1 52.00 Surface mounting box, single unit - 3
OAC-BS2 105.00 Surface mounting box, double unit - 3
OAC-DVA 182.00 Extruded aluminum front grille, single unit - 3
OAC-DVA2 367.00 Extruded aluminum front grille, double unit - 3
OACP-DIS203 100.00 Disconnect switch, double-pole, 20A at 240V 3 3
OACP-DIS403 117.00 Disconnect switch, triple-pole, 40A at 600V 3 3
OACP-R 104.00 24V control relay, without transformer 3 3
OACP-RT2 112.00 24V control relay, with transformer 3 -
OACP-T 84.00 Thermostat 3 3
OACP-T-BAR 52.00 Adaptor for T-bar ceiling installation, 23 3/4 in. X 23 3/4 in. (602 mm X 602 mm), single unit - 3
OACP-T-BAR2 105.00 Adaptor for T-bar ceiling installations, 23 3/4 in. X 47 11/16 in. (602 mm X 1211 mm), double unit - 3
