Products Catalog 2015-2016 •
81
OAC
1
Built-in thermostat included.
2
208V = 75% of wattage at 240V.
3
For the U.S. only: The nominal current of the unit must not exceed 80% of the capacity of the disconnect.
Add "BL" for white, "AM" for almond. Optional colors shown in the color chart section are available with a 10% upcharge.
For options available as factory installed and kit, if not mentioned on the order, will automatically be shipped as a kit.
277V available upon request.
Models
Watts
Volts
(ph)
Product #
1
Price
Unit
Weight
lb
kg
1500
120 (1)
OAC01502
453.00
single
24.0
10.9
2000
208 (1)
OAC02008
544.00
single
24.0
10.9
4000
208 (1)
OAC04008
544.00
single
24.0
10.9
4800
208 (1)
OAC04808
574.00
single
24.0
10.9
6000
208 (3)
OAC06038
1164.00
triple
90.0
40.9
8000
208 (1)
OAC08008
1247.00
double
50.0
22.7
9000
208 (3)
OAC09038
1561.00
triple
90.0
40.9
12000
208 (1)
OAC12008
1889.00
triple
90.0
40.9
12000
208 (3)
OAC12038
1889.00
triple
90.0
40.9
1500/1125
2
240/208 (1)
OAC01500
453.00
single
24.0
10.9
2000/1500
2
240/208 (1)
OAC02000
453.00
single
24.0
10.9
3000/2250
2
240/208 (1)
OAC03000
467.00
single
24.0
10.9
4000/3000
2
240/208 (1)
OAC04000
496.00
single
24.0
10.9
4800/3600
2
240/208 (1)
OAC04800
524.00
single
24.0
10.9
6000/4500
2
240/208 (1)
OAC06000
1102.00
double
50.0
22.7
8000/6000
2
240/208 (1)
OAC08000
1181.00
double
50.0
22.7
12000/9000
2
240/208 (1)
OAC12000
1831.00
triple
90.0
40.9
1500
347 (1)
OAC01507
653.00
single
28.0
12.7
2000
347 (1)
OAC02007
653.00
single
28.0
12.7
3000
347 (1)
OAC03007
675.00
single
28.0
12.7
4000
347 (1)
OAC04007
697.00
single
28.0
12.7
4800
347 (1)
OAC04807
736.00
single
28.0
12.7
6000
347 (1)
OAC06007
1439.00
double
50.0
22.7
8000
347 (1)
OAC08007
1655.00
double
50.0
22.7
12000
347 (1)
OAC12007
2381.00
triple
90.0
40.9
1500
480 (1)
OAC01504
685.00
single
28.0
12.7
2000
480 (1)
OAC02004
685.00
single
28.0
12.7
3000
480 (1)
OAC03004
705.00
single
28.0
12.7
4000
480 (1)
OAC04004
729.00
single
28.0
12.7
4800
480 (1)
OAC04804
769.00
single
28.0
12.7
6000
480 (1)
OAC06004
1441.00
double
50.0
22.7
8000
480 (1)
OAC08004
1655.00
double
50.0
22.7
12000
480 (1)
OAC12004
2381.00
triple
90.0
40.9
12000
480 (3)
OAC12034
2381.00
triple
90.0
40.9
1500
600 (1)
OAC01506
685.00
single
28.0
12.7
2000
600 (1)
OAC02006
685.00
single
28.0
12.7
3000
600 (1)
OAC03006
705.00
single
28.0
12.7
4000
600 (1)
OAC04006
729.00
single
28.0
12.7
4800
600 (1)
OAC04806
769.00
single
28.0
12.7
6000
600 (1)
OAC06006
1441.00
double
50.0
22.7
6000
600 (3)
OAC06036
1465.00
triple
90.0
40.9
8000
600 (1)
OAC08006
1655.00
double
50.0
22.7
9000
600 (3)
OAC09036
1965.00
triple
90.0
40.9
12000
600 (1)
OAC12006
2381.00
triple
90.0
40.9
12000
600 (3)
OAC12036
2381.00
triple
90.0
40.9
Options
Product #
Price
Description
Factory
Installed
Kit
OAC-BS1
52.00
Surface mounting box, single unit
-
3
OAC-BS2
105.00
Surface mounting box, double unit
-
3
OAC-BS3
153.00
Surface mounting box, triple unit
-
3
OAC-DIS20
3
100.00
Disconnect switch, double-pole, 20A at 277V and less
3
3
OAC-DIS40
3
117.00
Disconnect switch, triple-pole, 40A at 600V max.
3
3
OAC-DIS80
3
142.00
Disconnect switch, triple-pole, 80A at 600V max.
3
3
OAC-IV
98.00
Fan switch
3
-
OAC-O/O
104.00
On/Standby heating switch
3
-
OAC-R
104.00
24V control relay, without transformer
3
-
OAC-RT
112.00
24V control relay with transformer
3
-
