Products Catalog 2015-2016 •
8
OCT
Convector
Color
• Standard: white, metallic charcoal.
• Optional: almond, metallic silver, bronze, aluminum,
semi-gloss black (10% upcharge).
• Custom colors available upon request.
Finish
• Standard: epoxy/polyester powder paint.
Voltage
• 240/208V, 50/60 Hz, 1-phase.
Construction
• 20-gauge steel.
• Warm air outlet that directs the air to the centre of the room.
• Bar grilles prevent insertion of foreign objects;
smooth-finish paint is washable.
• High-limit temperature control with automatic reset.
Heating element
• 2 quiet aluminum monoblock elements.
Watt density
• 700W/ft. (2320W/m)
Control
• Built-in programmable or non programmable electronic thermostat
(-THP or -TH models)
Installation
• 4 in. (102 mm) minimum clearance to floor and from an adjacent wall.
• Quick surface-mounted installation, with the included wall
mounting bracket.
Warranty
• 2-year warranty against defects.
• 5-year warranty on the element.
(The warranty is valid only if the heater is controlled by a proportional pulsing
electronic thermostat with a cycle of 15 seconds.)
Application
• Kitchen, living room, family room, bedroom, basement.
Features
White
Metallic Charcoal
Models
Watts
Volts
Product #
Price
Product #
Price
Product #
Price
Length
Weight
Without Thermostat
1
Non Programmable
Integrated
Thermostat
Programmable
Integrated
Thermostat
in.
mm lb
kg
OCT Height: 17 1/2”(445 mm) 700W/ft. (2320W/m)
500/375 240/208
OCT0500
201.00
OCT0500-TH
237.00
OCT0500-THP
248.00
18
457
13
6
750/563 240/208
OCT0750
233.00
OCT0750-TH
274.00
OCT0750-THP
288.00
20 3/4
527.5 15.5
7
1000/750 240/208
OCT1000
252.00
OCT1000-TH
296.00
OCT1000-THP
311.00
23 9/16
598
16.7
7.6
1250/938 240/208
OCT1250
268.00
OCT1250-TH
315.00
OCT1250-THP
331.00
26 5/16
668.5 18.7
8.5
1500/1125 240/208
OCT1500
284.00
OCT1500-TH
334.00
OCT1500-THP
350.00
29 1/16
739
20
9.1
1750/1313 240/208
OCT1750
298.00
OCT1750-TH
350.00
OCT1750-THP
368.00
31 7/8
809.5
22
10
2000/1500 240/208
OCT2000
315.00
OCT2000-TH
370.00
OCT2000-THP
389.00
34 5/8
880
24
10.9
1
The OCT warranty is valid only if the heater is controlled by a proportional electronic pulsing line thermostat with a cycle of 15 seconds maximum.
Add "BL" for white, "CM" for metallic charcoal.
Optional colors shown in the color chart section are available with a 10% upcharge.
445 mm
17
1/2
"
23 mm
7/8
"
125.4 mm
4
15/16
"
Watts L (mm) L (in.)
500W 457.0 18
750W 527.5 20
3/4
1000W 598.0 23
9/16
1250W 668.5 26
5/16
1500W 739.0 29
1/16
1750W 809.5 31
7/8
2000W 880.0 34
5/8
Front View
Side View
Top View
