Products Catalog 2015-2016 •www.ouellet.com 7
Average StandardWatt Density Models 275W/ft. (900W/m)
ODL
Watts Watts
240/208V
Product # Length1 Weight
120V Price 208V 240/208V Price 347V 600V Price in. mm lb kg
300 300/225 ODL0302 147.00 ODL0308 ODL0300 121.00 - - - 24 5/8 625 7.4 3.4
500 500/375 ODL0502 155.00 ODL0508 ODL0500 127.00 ODL0507 - 145.00 29 1/2 750 8.5 3.9
750 750/563 ODL0752 179.00 ODL0758 ODL0750 147.00 ODL0757 ODL0756 171.00 39 1/2 1004 10.7 4.9
1000 1000/750 ODL1002 209.00 ODL1008 ODL1000 172.00 ODL1007 ODL1006 202.00 49 13/16 1265 13.0 5.9
1250 1250/938 ODL1252 255.00 ODL1258 ODL1250 205.00 ODL1257 ODL1256 242.00 59 1/4 1506 15.1 6.9
1500 1500/1125 ODL1502 269.00 ODL1508 ODL1500 219.00 ODL1507 ODL1506 261.00 68 1727 17.0 7.7
1750 1750/1313 - - ODL1758 ODL1750 263.00 ODL1757 ODL1756 315.00 77 5/16 1964 19.1 8.7
2000 2000/1500 - - ODL2008 ODL2000 287.00 ODL2007 ODL2006 334.00 86 1/8 2187 21.0 9.6
2250 2250/1688 - - ODL2258 ODL2250 318.00 ODL2257 ODL2256 372.00 94 15/16 2412 23.0 10.5
2500 2500/1875 - - ODL2508 ODL2500 341.00 ODL2507 ODL2506 397.00 104 1/16 2644 25.0 11.4
Options
1 Wall length = Length - 3/8" (9.5 mm).
2 These 2-wire relays with transformer can't supply of 3-wire low voltage thermostats.
3 "Off" position.
4 For the U.S. only: The nominal current of the unit must not exceed 80% of the capacity of the disconnect.
Add "BL" for white, "CM" for metallic charcoal.
Optional colors shown in the color chart section are available with a 10% upcharge.
Other voltages available upon request.
For options available as factory installed and kit, if not mentioned on the order, will automatically be shipped as a kit.
Product # Price Description Factory
Installed Kit
ODL-DIS204 101.00 Disconnect switch, double-pole, 20A at 277V max. 3 3
ODL-HA No Charge Linear high-limit temperature control for high altitude (3000 ft. at 8200 ft.) 3 -
ODL-R-347 55.00 Single-pole relay, coil 24V, without transformer: 22A at 120V, 208V, 240V - 18A at 347V 3 3
ODL-R-600 73.00 Single-pole relay, coil 24V, without transformer, 10A at 600V 3 3
ODL-RT-1202 140.00 Single-pole relay, coil 24V, with transformer 120V/24V, 25A at 120V (2-wire only) 3 3
ODL-RT-208 76.00 Single-pole relay, coil 24V, with transformer 208V/24V, 22A at 208V 3 3
ODL-RT-240 76.00 Single-pole relay, coil 24V, with transformer 240V/24V, 22A at 240V 3 3
ODL-RT-277 76.00 Single-pole relay, coil 24V, with transformer 277V/24V, 19A at 277V 3 3
ODL-RT-347 76.00 Single-pole relay, coil 24V, with transformer 347V/24V, 18A at 347V 3 3
ODL-RT-6002 109.00 Single-pole relay, coil 24V, with transformer 600V/24V, 10A at 600V (2-wire only) 3 3
ODL-TB6 30.00 Single-pole bi-metal thermostat: 25A at 120V, 208V, 240V, 277V - 10A at 347V, 480V, 600V 3 3
ODL-TB263 35.00 Double-pole bi-metal thermostat: 25A at 120V, 208V, 240V, 277V - 10A at 347V, 480V, 600V 3 3
ODL-TB6-AV 52.00 Single-pole bi-metal tamperproof thermostat: 25A at 120V, 208V, 240V, 277V - 10A at 347V, 480V, 600V 3 3
ODL-TB26-AV3 54.00 Double-pole bi-metal tamperproof thermostat: 25A at 120V, 208V, 240V, 277V - 10A at 347V, 480V, 600V 3 3
ODL-TRIAC-347 54.00 Single-pole electronic relay, coil 24V, without transformer, 15A at 347V max. 3 3
ODL-TRIAC-347T 74.00 Single-pole electronic relay, coil 24V, with transformer: 15A at 208V, 240V, 277V, 347V 3 3
ODL-TRIAC-600 98.00 Single-pole electronic relay, coil 24V, without transformer, 6A at 600V max. 3 3
Watts Watts
240/208V
Product # Length1 Weight
120V Price 208V 240/208V Price 347V 600V Price in. mm lb kg
300 300/225 ODL0302-750 155.00 ODL0308-750 ODL0300-750 127.00 - - - 29 1/2 750 8.5 3.9
500 500/375 ODL0502-1004 179.00 ODL0508-1004 ODL0500-1004 147.00 ODL0507-1004 - 171.00 39 1/2 1004 10.7 4.9
750 750/563 ODL0752-1265 209.00 ODL0758-1265 ODL0750-1265 172.00 ODL0757-1265 ODL0756-1265 202.00 49 13/16 1265 13.0 5.9
1000 1000/750 ODL1002-1506 255.00 ODL1008-1506 ODL1000-1506 205.00 ODL1007-1506 ODL1006-1506 242.00 59 1/4 1506 15.1 6.9
1250 1250/938 ODL1252-1727 269.00 ODL1258-1727 ODL1250-1727 219.00 ODL1257-1727 ODL1256-1727 261.00 68 1727 17.0 7.7
1500 1500/1125 ODL1502-2187 320.00 ODL1508-2187 ODL1500-2187 287.00 ODL1507-2187 ODL1506-2187 334.00 86 1/8 2187 21.0 9.6
1750 1750/1313 - - ODL1758-2412 ODL1750-2412 318.00 ODL1757-2412 ODL1756-2412 372.00 94 15/16 2412 23.0 10.5
2000 2000/1500 - - ODL2008-2644 ODL2000-2644 341.00 ODL2007-2644 ODL2006-2644 397.00 104 1/16 2644 23.3 10.5
2250 2250/1688 - - ODL2258-2644 ODL2250-2644 341.00 ODL2257-2644 ODL2256-2644 397.00 104 1/16 2644 23.3 10.5
Average LowWatt Density Models 200W/ft. (650W/m)
