Products Catalog 2015-2016 •
11
ORC
Sunshine
Radiant Cove Heater
Color and Finish
• Standard: silichem off-white, mat black and anodized aluminum finish.
Voltage
• 120V, 208V, 240V, 277V, 347V, 480V, 600V 50/60 Hz.
Construction
• Front made of an aluminum extrusion profiled
to increase radiating surface.
1
• Back of the unit made with 18-gauge steel.
• Junction box on each end.
• Wall installation brackets (supplied) that doesn’t require opening
the unit’s casing. KOE 7/8 in. (22 mm) for the installation of the BX wires.
2
• 4 in. (102 mm) ground wires on both ends.
3
• Wireway approved for interconnection of units using the factory installed
additional wires. This is used in wall-to-wall heater installation.
3
• Highly-emissive paint on the heat exchanger for higher efficiency.
Heating element
• Stainless steel tubular heating element inserted into a solid aluminum
extrusion preventing any thermal expansion noise.
Watt density
• 150W/ft. (491W/m).
Control
• Single or double-pole built-in thermostat available.
Ouellet highly recommends to use an electronic wall thermostat
for greater comfort.
Installation
• 6 ft. (1.83 m) minimum clearence to floor and 4 1/2 in. (114 mm)
minimum from ceiling.
• Variety of accessories available for wall-to-wall installation.
Warranty
• 1-year warranty against defects.
• 10-year warranty on the heating element.
Application
• Entrance way, bathroom, kitchen, living room, family room, bedroom,
patio door, bay window, daycare, nursery, workshop.
1
2
3
Features
Models
Watts
Product #
Price
Product #
Price
Length
Weight
120V
208V
240V
347V
600V
in.
mm
lb
kg
450
ORC0452 ORC0458 ORC0450
163.00
ORC0457
-
187.00
34
864
6.0
2.7
600
ORC0602 ORC0608 ORC0600
214.00
ORC0607
-
247.00
47
1194
8.0
3.6
750
ORC0752 ORC0758 ORC0750
251.00
ORC0757 ORC0756
289.00
59
1499
10.0
4.5
900
ORC0902 ORC0908 ORC0900
282.00
ORC0907 ORC0906
324.00
71
1803
12.0
5.4
1050
ORC1052 ORC1058 ORC1050
301.00
ORC1057 ORC1056
347.00
83
2108
13.0
5.9
1200
ORC1202 ORC1208 ORC1200
344.00
ORC1207 ORC1206
396.00
94
2388
15.0
6.8
1500
1
ORC1502 ORC1508 ORC1500
428.00
ORC1507 ORC1506
492.00
113
2870
18.0
8.2
Product #
Price
Description
Factory
Installed
Kit
ORC-JT
27.00
Splice plate
-
3
ORC-TB6
2
65.00
Single-pole bi-metal thermostat
3 3
ORC-TB26
2,3
79.00
Double-pole bi-metal thermostat
3 3
Options
1
These models must be ordered in pairs to reduce shipping damages.
2
Ouellet highly recommends to use an electronic wall thermostat for greater comfort.
3
"Off" position.
Add "BL" for silichem off-white, "NM" for mat black and "AA" for anodized aluminum finish.
For options available as factory installed and kit, if not mentioned on the order,
will automatically be shipped as a kit.
114 mm
4
1/2
"
864 mm to 2870 mm
34" to 113”
39 mm
1
1/2
"
107 mm
4
1/4
"
180 mm
7
1/16
"
79 mm
3
1/8
"
47 mm
1
7/8
"
Side View
Rear View
Top View
Wall
Ceiling
