Products Catalog 2015-2016 •
6
ODL
Sublime
High-End Baseboard Heater
Color
• Standard: white, metallic charcoal.
• Optional: almond, metallic silver, bronze, aluminum,
semi-gloss black, sand (10% upcharge).
• Custom colors available upon request.
Finish
• Standard: epoxy/polyester powder paint.
Voltage
• 120V, 208V, 240/208V, 277V, 347V, 480V, 600V, 1-phase.
Construction
• Robust aluminum front cover.
• 20-gauge satin coat steel cabinet.
• Linear high-limit temperature control with automatic reset.
• High altitude version available (-HA).
Heating element
• Stainless steel tubular heating element with aluminum fins.
• Floating heating element on high-temperature nylon bushings
eliminating expansion noises.
Watt density
• Average standard watt density of 275W/ft. (900W/m).
• Average low watt density of 200W/ft. (650W/m).
Control
• Built-in thermostat available with a control knob or tamperproof.
• Mechanical or electronic relays available
(installed on the right end only).
• Compartment for low voltage connections (located directly
under the junction box) to facilitate the installation of low voltage relay.
Ouellet highly recommends the use of an electronic wall thermostat
for greater comfort.
Installation
• Installation directly on the floor.
• Connection box at both ends.
• Single-screw built-in wire holder.
• Raceway for ease of installation.
• Two rows of mounting holes spaced at 2 in. (51 mm) intervals
for ease of installation.
Warranty
• 1-year warranty against defects.
• Heating element has a lifetime warranty for the initial end user.
Application
• Dining room-kitchen, living room, family room, bedroom, bay window,
office building, commercial building.
Features
Side View
BottomView
Rear View
46 mm
1
13/16
"
47 mm
1
13/16
"
113 mm
4
7/16
"
80 mm
3
1/8
"
73 mm
2
7/8
"
177 mm
6
15/16
"
162 mm
6
3/8
"
21 mm
13/16
"
104 mm
4
1/8
"
33 mm
1
5/16
"
27 mm
1
1/16
"
51 mm
2"
KOE Ø22 mm
KOE Ø
7/8
"
Length
Wall Length = Length -
3/8
" (9.5 mm)
KOE Ø22 mm
KOE Ø
7/8
"
KOE Ø13 mm
KOE Ø
1/2
"
VERSIONAVAILABLE
