Products Catalog 2015-2016 •
35
Models
Watts
Product #
240/208V
Cable
Diameter
(mm)
Product #
120V
Cable
Diameter
(mm)
Price
Covered Surface
2
Spacing 3" (76 mm)
Length (x)
Weight
sq. ft.
sq. m ft.
m
lb
kg
85
-
-
OTM0082
4.196
219.00
8
0.7
6’
1.8
2.0
0.9
120
-
-
OTM0122
4.504
232.00
10
0.9
7’6"
2.3
2.0
0.9
150
-
-
OTM0152
4.306
262.00
13
1.2
10’
3.0
3.0
1.4
170
OTM0170
4.196
OTM0172
4.240
277.00
15
1.4
11’6"
3.5
3.0
1.4
240
OTM0240
4.504
OTM0242
4.174
336.00
20
1.9
15’
4.6
3.0
1.4
300
OTM0300
4.306
OTM0302
4.196
386.00
25
2.3
19’
5.8
3.0
1.4
360
OTM0360
4.240
OTM0362
4.064
425.00
30
2.8
22’6"
6.9
4.0
1.8
420
OTM0420
4.394
OTM0422
4.196
465.00
35
3.3
26’6"
8.1
5.0
2.3
475
OTM0475
4.174
OTM0472
4.306
485.00
40
3.7
30’
9.1
5.0
2.3
600
OTM0600
4.196
OTM0602
4.042
578.00
50
4.6
37’6"
11.4
7.0
3.2
720
OTM0720
4.064
OTM0722
4.174
664.00
60
5.6
45’
13.7
7.0
3.2
840
OTM0840
4.196
OTM0842
4.328
739.00
70
6.5
52’6"
16.0
9.0
4.1
960
OTM0960
4.306
OTM0962
4.482
811.00
80
7.4
60’
18.3
10.0
4.5
1080
OTM1080
4.438
-
-
895.00
90
8.4
67’6"
20.6
11.0
5.0
1140
-
-
OTM1142
4.536
950.00
95
8.83
71' 4"
21.7
11.25
5.1
1200
OTM1200
4.042
-
-
956.00
100
9.3
75’
22.9
12.8
5.8
1320
-
-
OTM1322
4.714
1088.00
110
10.22
82' 6"
25.1
15.0
6.8
1440
OTM1440
4.174
-
-
1121.00
120
11.1
90’
27.4
13.0
5.9
1500
-
-
OTM1502
4.982
1221.00
125
11.61
93' 10"
28.6
19.0
8.6
1600
OTM1600
4.328
-
-
1266.00
140
13.0
105’
32.0
16.0
7.3
1680
-
-
OTM1682
5.294
1353.00
140
13.01
105'
32.0
20.5
9.3
1920
OTM1920
4.482
-
-
1391.00
160
14.9
120’
36.6
21.9
9.9
2280
OTM2280
4.536
-
-
1778.00
190
17.65
142' 6"
43.4
22.5
10.2
2640
OTM2640
4.714
-
-
2011.00
220
20.44
165'
50.3
30.0
13.6
3000
OTM3000
4.982
-
-
2244.00
250
23.23
187' 6"
57.2
38.0
17.3
3360
OTM3360
5.294
-
-
2414.00
280
26.01
210'
64.0
41.0
18.6
OTM
Models
Watts
Product #
1
240/208V
Cable
Diameter
(mm)
Product #
1
120V
Cable
Diameter
(mm)
Price
Covered Surface
2
Spacing 3" (76 mm)
Covered Surface
2
Spacing 3 1/2" (88 mm)
Length (x)
Weight
12W/sq. ft. 130W/sq. m 10W/sq. ft.
108W/sq. m ft.
m lb kg
85
-
-
OTR0082
4.196
121.00
8
0.7
8
0.7
32 9.75 3.5
1.6
120
-
-
OTR0122
4.504
129.00
10
0.9
12
1.1
40 12.19 3.5
1.6
150
-
-
OTR0152
4.306
146.00
13
1.2
16
1.5
52 15.85 4.2
1.9
170
OTR0170
4.196
OTR0172
4.240
156.00
15
1.4
18
1.7
60 18.29 3.9
1.8
240
OTR0240
4.504
OTR0242
4.174
193.00
20
1.9
24
2.2
80 24.38 4.2
1.9
300
OTR0300
4.306
OTR0302
4.196
222.00
25
2.3
30
2.8
100 30.48 4.5
2.0
360
OTR0360
4.240
OTR0362
4.064
247.00
30
2.8
36
3.3
120 36.58 5.5
2.5
420
OTR0420
4.394
OTR0422
4.196
254.00
35
3.3
42
3.9
140 42.67 5.7
2.6
475
OTR0475
4.174
OTR0472
4.306
261.00
40
3.7
48
4.5
160 48.77 6.2
2.8
600
OTR0600
4.196
OTR0602
4.042
307.00
50
4.6
60
5.6
200 60.96 7.6
3.4
720
OTR0720
4.064
OTR0722
4.174
345.00
60
5.6
72
6.7
240 73.15 8.4
3.8
840
OTR0840
4.196
OTR0842
4.328
356.00
70
6.5
84
7.8
280 85.34 8.5
3.8
960
OTR0960
4.306
OTR0962
4.482
406.00
80
7.4
96
8.9
320 97.54 9.5
4.3
1080
OTR1080
4.438
-
-
427.00
90
8.4
108
10
360 109.73 10.6 4.8
1200
OTR1200
4.042
-
-
475.00
100
9.3
120
11.1
400 121.92 11.5 5.2
1440
OTR1440
4.174
-
-
486.00
120
11.2
144
13.4
480 146.30 12.7 5.8
1600
OTR1600
4.328
-
-
590.00
140
13.0
168
15.6
560 170.69 14.7 6.6
1920
OTR1920
4.482
-
-
670.00
160
14.8
192
17.8
640 195.07
17.0 7.7
Product #
Price
Description
Factory
Installed
Kit
OTM-CC
28.00
CableCheck - Electrical fault indicator
-
3
OTM-KIT
34.00
Repair kit
-
3
OTM-SA
28.00
Adhesive spray to secure the mat on concrete slab, 16.75 oz (474 g)
-
3
OWF-G25-P
13.00
25 ft. plastic strapping for products
-
3
OWF-S
22.00
15 ft. (4.6 m) foor sensor
-
3
OTM and OTR Options
OTR
1
Strapping not included. If required, please order separately the OWF-G25-P.
2
Does not represent the surface of the room but rather the surface covered by the floor heating system, excluding fixtures and other spaces to consider.
208V = 75% of wattage at 240V.
15’ (4.6 m) floor sensor and 13’ 6" (4.2 m) cold lead included.
